Load Plate Size Ø300mm Dual Axis Motion Simulators with Chamber for INS Testing Load capacity 30/50kg

Product Categories
Shenzhen Fire Power Control Technology Co., LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Load Plate Size Ø300mm Dual Axis Motion Simulators with Chamber for INS Testing Load capacity 30/50kg

  • 1
  • 2

Brand Name : Firepower

Model Number : 2LT300-W

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 10 pcs/5 months

Delivery Time : 5 months

Packaging Details : Wooden Box

Product Name : Acceleration Test Turntable

Load capacity : 30/50kg

Load Plate Size : Ø300mm

Rate Range : ±0.001°/s~1000°/s

Angular Position Measure Accuracy : ±3''

Rotary Accuracy : ±1~3''

Axes Perpendicularity : 3''

Table height : 40０mm

Contact Now

Dual Axis Motion Simulators with Chamber for INS Testing

Products Description
Two-axis temperature turntable with temperature chamber is composed of three parts: mechanical platformbody, measurement and control system and temperature control system. The platform body adopts U-T structureform and precision mechanical shafting, internal orientation and external pitching, with position and speedmovement functions, providing accurate single axis and double axis positioning and rate reference for themeasured oad, The temperature control box provides hioh and low temperature test environment for the oadUsed for static testing and calibration of inertial element components and inertial navigation systems.
Specification
Maximum load weight
30/50KG
Table size
Φ300mm
Mesa flatness
0.02mm
Table height
400mm
Face runout
0.05mm
Rotation accuracy
±1~3″
Angular position range
±0〜 ±360°
Angular position accuracy
±1~3″
Angular resolution
0.0001°
Angular rate range
0.001〜10000°/s
Angular rate accuracy
ω＜1°/s
1<ω＜10°/s
10<ω°/s
Speed smoothness
1 × 10-3
1 × 10-4
5 × 10-5
Max angular acceleration
10000°/s2(Optional)
Rocking function
Optional
Rate resolution
0.0001°
Slip ring number
10~72(Optioanl)
System bandwidth
5~ 80Hz(Optioanl)
Slip-ring voice
≤±0.03V
Leakage flux
<0.5mT
MTBF
≥2000h
Tempe. control accuracy
±0.5°
Tempe. uniformity
2°

Product Display
